Architectural Builders Hardware Mfg. Inc. (ABH) is a high quality manufacturer of Overhead Holders & Stops, Hospital Latches, Electromagnetic Holders, Pivots, Strikes and Rescue Stops, Aluminum Hinges, Stainless Steel Hinges, Coordinators, Flush Bolts, Power Wire Transfers, and Roller Latches.

Features:

• Surface Mount
• Extra Heavy Duty
• NY SCA approved
• Single-acting doors only
• Non-handed
• For interior or exterior use on frequent traffic and heavy weight doors
• Standard installation from 85° to 110° of opening (5° increments)
• Shock absorbing spring provides 3° to 5° cushion before dead-stop
• Standard fasteners supplied with sex bolts for 1-3/4" to 2-1/4" thick door
• UL Listed as Miscellaneous Fire Door Accessories for use on wood fire doors rated up to 90 minutes and metal fire doors rated up to 3 hurs (stop function only)
• Average weight per unit = 5 lbs

Hinges or Offset Pivots	Center Hung	Hold-Open	Stop
27" - 32-7/16"	29-1/2" - 34-15/16"	8010	8020
32-1/2" - 38-11/16"	35" - 41-7/16"	8011	8021
38-3/4" - 42-7/16"	41-1/2" - 44-15/16"	8012	8022
42-1/2" - 54"	45" - 56"	8013	8023

Downloads:
