Product Description
-
1/2.7" 5MP PS CMOS Image Sensor (0.9407cm)
-
Maximum 25/30fps@5MP
-
DWDR, 2D-DNR, AWB, AGC, BLC, HLC
-
3.6mm Fixed Lens
-
Illumination Range of 20 Mtrs, IP67
-
Support Built-in Mic
-
CVI/CVBS/AHD/TVI switchable
-
System Overview
-
With the help of the new Guard Series of Cameras by CP PLUS, surveillance at night has substantially been made easier as vividly colorful images can be captured even in a completely dark scene
-
The lead-ing part in this highly efficient surveillance solution is played by the 5MP Full-Color Cameras that show the detailing in the varied colors of the object in the sce- ne even during night time
-
Functions
-
Full Color
-
The Full-Color technology that has been ingrained in this camera lets you enjoy an image in full-color even during night time as this technology automatically illuminates the image with the accurate detailing of colors from the scene
-
LED Range
-
Numerous crystal IR LEDs provide detailed images even in very low light conditions
-
These LEDs adjust the infrared intensity for distinct images in dark environments for up to 20mtrs
-
Power Protection
-
With a voltage tolerance range of ±30, these cameras are suitable even in fluctuating power conditions
-
UNI Technology
-
CP PLUS Analog HD cameras offer compatibility across all the available technologies - CVBS, TVI, HDCVI and AHD making upgrading simple and hassle-free
-
Plug & Play
-
CP PLUS Guard cameras are simple to configure and install
Product Specification
| Brand | CP Plus |
| Product Type | Dome Camera |
| Product Code | CP-GPC-DA50PL2C-SE |
| Image Sensor | 1/2.7" 5MP PS CMOS (0.9407cm) |
| Minimum Illumination | 0.005Lux/F1.6, 0Lux White Light on |
| Body Type | Dome |
| Shutter Speed | PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
| Maximum Aperture | F1.6 |
| White Balance | Auto/Manual |
| Lens Type | Fixed |
| Lens | 3.6mm |
| Gain Control (AGC) | Auto/Manual |
| DORI Distance | 3.6mm: 80m(Detect), 32m(Observe), 16m(Recognize), 8m(Identify) |
| Angle Of View | 3.6 mm: 109° × 92° × 48° (diagonal × horizontal × vertical) |
| S/N Ratio | >65dB |
| Back Light Compesation | BLC/ HLC/ DWDR |
| Video Streaming | CVI: PAL: 5M@25fps; 4M@25fps; 1080P@25fps; NTSC: 5M@25fps; 4M@30fps; 1080P@30fps; AHD: PAL: 4M@25fps; NTSC: 4M@30fps TVI: PAL: 4M@25fps; NTSC: 4M@30fps CVBS: PAL: 960H; NTSC: 960H |
| Privacy Mask | Off/on (8 area, rectangle) |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Input | Built-in Mic |
| Illumination Distance | Illumination Range of 20 Mtr |
| Operating Temperature | -40°C ~ 55°C; Less than <95% RH (non-condensation) |
| Power Source | 12V DC ±30% |
| Power Consumption | Maximum 3.0W (12V DC, White Light on) |
| Weatherproof Standard | IP67 |
| Casing | Plastic |
| Dimension | φ97 × 86.6 mm |
| Warranty | As Per Manufacturer Terms and Condition |
