Product Description
-
1/2.7” 5MP Progressive scan CMOS Image Sensor (0.9407 centimetres)
-
Max 25fps@5MP (16:9 video output)
-
DWDR, Day/Night (ICR), 2D-NR, AWB, AGC, BLC, HLC
-
3.6mm Fixed lens (2.8mm, 6mm, 8mm optional)
-
IR Range of 80Mtrs., Smart IR, IP67
-
Support Built-in Mic
-
CVI/CVBS/AHD/TVI switchable
-
Support Starlight Technology
-
Functions
-
LED
-
LEDs provide detailed images even in very low light conditions
-
These LEDs adjust the infrared intensity for distinct images in dark environments for up to 80mtrs
-
UNI Technology
-
CP PLUS Analog HD cameras offer compatibility across all the available technologies - CVBS, TVI, HDCVI, AHD and HDx,making upgrading simple and hassle-free
-
OSD Menu Support
-
CP PLUS HD analog cameras come with their own menu using which the camera settings can be managed, for instance, the signal type can be changed and other sensor level adjustments
be made -
Starlight Technology
-
This camera is widely used to provide sharper and clearer picture quality with the help of its exceptional starlight sensitivity as the camera improves night vision in low light conditions
-
This technology is useful in conditions with extremely low light as the starlight technology turns almost completely dark images into those of clear colors
-
Power Protection
-
With a voltage tolerance range of ±30, these cameras are suitable even in fluctuating power conditions
-
Plug & Play
-
CP PLUS Analog HD cameras are simple to configure and install
Product Specification
| Brand | CP Plus |
| Product Type | Bullet Camera |
| Product Model | CP-USC-TA50L8C-S |
| Image Sensor | 1/2.7" 5MP PS CMOS (0.9407 centimetres) |
| Minimum Illumination | 0.005 Lux/F1.6, 30IRE, 0 Lux IR on |
| Effective Pixels | 2880 (H) × 1620 (V) |
| Shutter Speed | PAL: 1/25s–1/100000s ; NTSC: 1/30s–1/100000s |
| White Balance | Auto / Manual |
| Close Focus Distance | 3.6mm: 1.6 m (5.2 ft); 2.8mm: 0.9 m (3.0 ft); 6mm: 3.1 m (10.2 ft); 8mm: 4.9 m (16.1 ft) |
| Mount Type | M12 |
| Maximum Aperture | F1.6 |
| Lens Type | Fixed-Focal |
| Iris Type | Fixed Iris |
| Lens | 3.6mm (2.8mm, 6mm, 8mm optional) |
| DORI Distance | 3.6mm: 80m (Detect) 32m (Observe) 16m (Recognize) 8m (Identify) |
| S/N Ratio | >65dB |
| Back Light Compensation | BLC/HLC/DWDR |
| Angle Of View | 3.6mm: 109° × 92° × 48° (diagonal × horizontal × vertical) |
| Video Streaming | CVI: PAL: 5M@25fps; 4M@25fps; 1080P@25fps; NTSC: 5M@25fps; 4M@30fps; |
| Resolution | 5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960H (960 × 576/960 × 480) |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio | One Channel Built-in Mic |
| ICR | Auto switch by ICR |
| Noise Reduction | 2D-NR |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Gain Control (AGC) | Auto/Manual |
| IR | IR Range of 80Mtr., Smart IR |
| Power Source | 12V DC ±30% |
| Power Consumption | Maximum 5.2W (12V DC, IR on) |
|
$
