Brand

Dahua

Product Type

Bullet Camera

Product Model

DH-HAC-HFW1220TLP

Series

Lite

Camera

Image Sensor

1/2.8" CMOS

Effective Pixels

1920(H)×1080(V), 2MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25~1/100000s

NTSC: 1/30~1/100000s

Minimum Illumination

0.01Lux/F1.6, 0Lux white light on

S/N Ratio

More than 65dB

IR Distance

Distance up to 20 m (65.61 ft)

IR On/Off Control

Auto / Manual

IR LEDs

1

Lens

Lens Type

Fixed lens / Fixed iris

Mount Type

M12

Focal Length

3.6mm (2.8mm Optional)

Max Aperture

F1.6

Angle of View

2.8 mm: 126.2° × 106° × 56.5° (diagonal × horizontal × vertical);

3.6 mm: 103.6° × 86.9° × 46.3° (diagonal × horizontal × vertical)

Focus Control

N/A

Close Focus Distance

2.8 mm: 0.6 m (1.97 ft); 3.6 mm: 1.2 m (3.94 ft)

DORI Distance Definition

Dori Definition

Distance

Detect

25px/m (8px/ft)

2.8mm: 37m(122ft) 3.6mm: 53m(175ft) 6mm: 80m(262ft)

Observe

63px/m (38px/ft)

2.8mm: 15m(49ft) 3.6mm: 21m(70ft) (19px/ft) 6mm: 32m(105ft)

Recognize

125px/m (38px/ft)

2.8mm: 8m(25ft) 3.6mm: 11m(35ft) 6mm: 16m(52ft)

Identify

250ppm (76px/ft)

2.8mm: 4m(12ft) 3.6mm: 5m(17ft) 6mm: 8m(26ft)

Pan / Tilt / Rotation

Pan/Tilt/Rotation

Pan: 0° ~ 360°,Tilt: 0° ~ 90°,Rotation: 0° ~ 360°

Video

Resolution

1080P (1920 × 1080); 720P (1280 × 720); 960H (960 × 576/960 × 480

Frame Rate

CVI: PAL: 1080P@25fps; 720P@25fps;

NTSC: 1080P@30fps; 720P@30fps;

AHD: PAL: 1080P@25fps; NTSC: 1080P@30fps

TVI: PAL: 1080P@25fps; NTSC: 1080P@30fps

CVBS: PAL: 960H; NTSC: 960H

Video Output

1-channel BNC high definition video output / CVBS video output (Can switch)

Day/Night

Auto (ICR) / Manual

OSD Menu

Multi-language

BLC Mode

BLC / HLC / DWDR

WDR

<
