Product Description
-
Max 30fps@1080P
-
HD and SD output switchable
-
2.8mm fixed lens (3.6mm optional)
-
Max. IR length 20m, Smart IR
-
Built-in PIR, 10m/110°detecting range/angle
-
Active deterrence with white light & siren
-
IP67, DC12V
-
Functions
-
4 Signals over 1 Coaxial Cable
-
Long Distance Transmission
-
Simplicity
-
Dual Detection
-
Active Deterrence
-
Smart IR
-
Broadcast-quality Audio
-
Protection
Product Specification
Brand |
Dahua |
||
Product Type |
Bullet Camera |
||
Series |
PIR Series |
||
Product Model |
DH-HAC-ME1200DP |
||
Camera | |||
Image Sensor |
1/2.7" CMOS |
||
Effective Pixels |
1920(H)×1080(V), 2MP |
||
Scanning System |
Progressive |
||
Electronic Shutter Speed |
PAL: 1/25~1/100000s NTSC: 1/30~1/100000s |
||
Minimum Illumination |
0.02Lux/F2.0, 30IRE, 0Lux IR on |
||
S/N Ratio |
More than 65dB |
||
Ir Distance |
Up to 20m (66feet) |
||
Ir On/Off Control |
Auto / Manual |
||
Ir Leds |
1 |
||
Lens | |||
Lens Type |
Fixed lens / Fixed iris |
||
Mount Type |
Board-in |
||
Focal Length |
2.8mm/3.6mm |
||
Max Aperture |
F2.0/F2.0 |
||
Angle Of View |
2.8mm: H: 111°, V: 60.5° 3.6mm: H: 88°, V: 47.5° |
||
Focus Control |
N/A |
||
Close Focus Distance |
500mm/900mm 19.7''/35.4'' |
||
Dori Distance | |||
Dori Definition |
Distance |
||
Detect |
25px/m (8px/ft) |
2.8mm: 37m(122ft) 3.6mm: 53m(174ft) |
|
Observe |
63px/m (19px/ft) |
2.8mm: 15m(49ft) 3.6mm: 21m(69ft) |
|
Recognize |
125px/m (38px/ft) |
2.8mm: 8m(25ft) 3.6mm: 11m(36ft) |
|
Identify |
250ppm (76px/ft) |
2.8mm: 4m(12ft) 3.6mm: 5m(16ft) |
|
Pan/Tilt/Rotation |
Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotation: 0° ~ 360° |
||
Video | |||
Resolution |
1080P (1920×1080) |
||
Frame Rate |
25/30fps@1080P, 25/30/50/60fps@720P |
||
Video Output |
1-channel BNC high definition video output / CVBS video output (Can switch) |
||
Day/Night |
Auto (ICR) / Manual |
||
$
