Features

• Safe design with input and output electrical isolation.
• Adoption of advanced SPWM technology, pure sine wave output.
• Optional output voltage 220/230VAC, choosing by DIP switch.
• LED indicators for fault status and working status.
• Lower No-load consumption.
• Max. efficiency up to 95%.
• Input protection: Over voltage protection, low voltage protection.
• Output protection: Overload protection, short circuit protection.
• Over temperature protection: Temperature-controlled Fan Ventilation; Inverter turns off automatically when overheating.

Technical Specification

• Model: IP1500-22.
• Rated Input Voltage: 24VDC.
• Input Voltage Range: 21.6 to 32VDC.
• Input surge voltage: ＜40VDC.
• Output Voltage: 220VAC (± 5%), 230VAC (-7% ~ 5%).
• Output Frequency: 50/60±0.1Hz
• Output Continuous Power: 1200W.
• Power Factor: 0.2-1(VA lower than output continuous power).
• Output Wave: Pure sine wave.
• Overall dimension: 284.7mm × 231.5mm × 98.5mm.
• Net weight: 3.9 kg.
