Product Description
-
Traffic Management
-
Auto Negotiation of speed and duplex modes
-
IEEE 802.3x Flow Control
-
Dynamic MAC address management
-
IEEE 802.1Q-based VLAN
-
Auto Voice VLAN
-
Auto Video VLAN
-
QoS based on WRR, strict priority, or both
-
Port-based and IEEE 801.2p-based QoS
-
TCP/UDP-based QoS
-
DiffServ
-
DSCP Support
-
Rate Limiting (ingress, or egress)
-
Link Aggregation and LACP
-
Switch Management
-
Web browser-based management GUI
-
Smart Control Center Software for multi-switch management
-
IP Access List
-
Configurable Management VLAN
-
SNMP v1/v2c and v3
-
Standard MIBs (RFC1213, RFC1643, and RFC1493)
-
RMON group 1, 2, 3, 9
-
Firmware Upgrade through Smart Control Center (TFTP)
-
Firmware download (to switch) and upload (to server) through TFTP/HTTP
-
Configuration and Image Upload (to PC) through HTTP
-
Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)
-
Memory & FLASH log
-
Syslog (server)
-
System password protection
-
Registration through NETGEAT Insight App
-
Spanning Tree, Routing And Stacking
-
IEEE 802.1D Spanning Tree Protocol (STP)
-
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
-
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
-
Reliability, Performance And Troubleshooting
-
Port mirroring both on ingress and egress traffic
-
Jumbo frame support
-
Broadcast Storm control
-
Cable diagnostics
-
Loop Detection
-
DoS Prevention
-
IEEE 802.1ab LLDP
-
LLDP-MED
-
Dual Image
-
SNTP
Product Specification
| Brand | Netgear |
| Product Type | POE Switch |
| Product Model | GS324TP |
| 10M/100M/1G RJ-45 Copper Ports | 24 |
| PoE / PoE Ports | 24 PoE (190W PoE budget) |
| 1G SFP (fiber) Ports | 2 (dedicated) |
| Performance Specification | |
| CPU | 800MHz 512MB RAM 128MB FLASH |
| Packet Buffer Memory (Dynamically Shared Across Only Used Ports) | 512KB |
| Forwarding Modes | Store-and-forward |
| Bandwidth | 52 Gbps |
| Priority Queues | 4 |
| Priority Queuing | Weighted Round Robin (WRR) and Strict Priority |
| MAC Address Database Size (48-Bit MAC Addresses) | 16K |
| Multicast Groups | 512 |
| Number Of VLANs | 64 |
| Number Of DHCP Snooping Bindings | 8K |
| Access Control Lists (ACLs) | 100 shared for MAC (ingress) |
| Packet Forwarding Rate (64 Byte Packet Size) (Mpps) | 38.6 |
| Jumbo Frame Support (Bytes) | 9216 |
| Acoustic Noise Level 25°C (dBA) (ANSI-S10.12) | 32.8dBA |
| Mean Time Between Failures (MTBF) 25°C | 1,328,429 hrs (152 yrs) |
| 1G Copper Latency (64-Byte; 1518-Byte; 9216-Byte Frames) | 3.734μs; 3.749μs; 3.807μs |
| 1G Fiber Latency (64-Byte; 1518-byte; 9216-Byte Frames) | 2.896μs; 2.903μs; 2.914μs |
| L2 Services - VLANs | |
| IEEE 802.1Q VLAN Tagging | Yes |
| IP-Based VLANs | Yes |
| MAC-Based VLANs | Yes |
| Auto-Voice VLAN | Yes, based on OUI bytes (default database and user-based OUIs) in the phone source |
| Auto-VOIP | Yes, based on protocols (SIP) Prioritzes traffic to a higher queue |
| Voice VLAN | Yes, based on either VLAN ID or 802.1p priority, packets are passed onto the connecting VoIP |
| Auto-Video VLAN | Yes |
| LEDs | |
| Per Port | Speed,
$
