Product Details
＋
The DW-200 dual technology wall switch sensor combines the benefits of passive infrared (PIR) and ultrasonic technologies to turn lights ON and OFF based on occupancy. It contains two relays for controlling two independent lighting loads or circuits and a variety of features.
Features
- Wallplate Not Included
- Finish: Black, Grey, Ivory, Light Almond, White
- Voltage: 120/277 VAC
- Load Rating:
- 120 VAC: 0-800 W ballast or tungsten,1/6 hpSwitchesli
- 277 VAC: 0-1200 W ballast
- Light Output 1FCD: Automatic On/Off, Manual On/Off
- Response Time: 5 to 30 minutes
- High sensitivity and dense coverage for exceptional performance
- Two relays for control of two separate lighting loads or circuits
- Color-matched lens and low profile for appealing design
- Selectable operation, walk-through, test and presentation modes for increased energy savings and convenience
- Part of a comprehensive line of PIR, Ultrasonic and Dual Technology wall switch sensors
- Defaults to Auto-ON to 50% operation for maximum energy savings
- Typical Applications: Small and executive offices, small and medium conference rooms and lunch/break rooms
Dimensions
- Width: 3"
- Height: 2.5"
- Depth: 5"
